SolaX X1-MINI G4 – Single-Phase Residential On-Grid Inverter

SolaX X1-MINI G4 is a single-phase residential on-grid inverter available in 0.6kW, 0.7kW, 0.8kW, 1.1kW, 1.5kW, 2.0kW, 2.5kW, 3.0kW and 3.3kW models, built for high efficiency and assured safety in small residential solar installations.

Key Features

• 200% PV oversizing and 16A input to support high-power panels
• Ultra-wide MPPT voltage range with built-in global MPP scan
• Built-in export power control function
• Supports parallel operation for up to 5 inverters, no external EMS required
• Smart loads management (e.g. heat pump, smart EV charger)
• 10s data refresh on SolaXCloud, IV curve scan
• Type II SPD on AC & DC side, optional AFCI support
• IP66 ingress protection, ready for rapid shutdown function

Shared Technical Specifications

MPP Trackers: 1 (1 string) | Max. Input Current per MPPT: 16A | Max. Input Short-Circuit Current: 22A | Rated AC Voltage: 220/230/240V, 1/N/PE | Rated AC Frequency: 50Hz/60Hz | Max. Efficiency: 98.0% | Ingress Protection: IP66 | Operating Temp: -25°C to 60°C (>45°C derating) | Dimensions (W x H x D): 290 x 206 x 120mm | Communication: RS485, DRM, optional meter/CT | Topology: Non-isolated | Power Consumption (night): <1W

Per-Model Specifications
